Introduction

MVCM-6010-A1 ANPR all-in-one machine is an Al intelligent product that supports multi-country license plate recognition. The built-in deep learning intelligent algorithm ofthe device can quickly identify multi-country license plates through video detection and capture. Products are widely used in residential areas, shopping malls, schools, hospitals.airports, parks, public parking lots and other vehicle entrance and exit scenes.

Features

Accurately Recognize of Multinational License Plates

Intelligent Fill Light

Adaptive Speed Capture

High Open Configuration Capability

Black and White List

Voice Broadcast

Real-time Video Surveillance

Parameters

License Plate Recognition Rate

When the recognition angle is ≤45" and the speed is within 30Km/h, the correct recognition rate of the license plate is ≥99%

Sensor Pixel

1/3 "Progressive Scan CMOS

lmage Forma

JPEG

lmage Resolution

2880*1616

Videu Resolulion

2880*1616/1920~1080/1280~720/720*576/640*480

Max Frame Rate

30fps, adjustable frame rate

Video Compression Standards

H.264, H.265,bitstream 256Kbps-8Mbps, adjustable

Network

one 100M network port

Audio

Built-in speaker

Relay Output

1 Output

Serial Port

1 RS485

Working Voltage

AC220V/110V土10% 50-60Hz

Power Consumption

<70W

Operating Temperature and Humidit

-30°C-+65°C 5%-95% (no condensation)

Ingress Protection

IP65

Product Dimension

194mm (L)130mm (w) "1360mm (H)

Installation Mode

floor cabinet installation
