Introduction

Fire Fighting Robot (Foam Spraying) is a device specifically designed for firefighting tasks. lt is primarily used in hazardous areas like petrochemical sites, oil tank farms, large warehouses, and buildings where high temperatures, intense heat radiation, andpotential collapses make it difficult for fire trucks and personnel to access. By using the firefighting foam robot, personnel casualtiescan be avoided, and effective firefighting and cooling can beachieved.

Features

Dual-Purpose Water/Foam Cannon

Extended-Range Wireless Operation

High-Capacity Battery

Ultrasonic Obstacle Avoidance

Parameters

Battery Voltage

DC 48V

Motor Power

3.15kW * 2

Maximum Speed

1.8m/s

Autonomy

≥3.5h

Battery Capacity

200Ah

Charging Time

≤8h

IP Rating

IP66

Ground Clearance

165mm

IECEx Rating

Ex db eb mb llB T4 Gb

Gas Detection

EX, CO, O₂, H₂S, SO₂, NH₃, HCl, NO₂ (Customizable)

Control Mode

10.1-Inch Display with Wireless Remote Control

Minimum Turning Radius

850mm

Maximum Lifting Height

1645mm

Traction Force

5020N

Water Flow Rate

40L/s

Foam Flow Rate

96,000L/min

Foam Spray Range

≥45m

Inlet Pressure

8bar

Foam Expansion Ratio

30~40

Foam Consumption

1.8L/s

Weight

≤560kg

Product Size

≈1690*1035*1245mm
