Introduction

The Intelligent Lock Tracker is a device used for rea-time supervision of goods in transit transport status. The device adopts dual SIM card slot design, equipped with dual-mode positioning module to achieve accurate positioning, real-time communication, automatic tracking and positioning. At the same time, it has the function of large-capacity blind one data recording, which automatically stores local data when the device is in the blind zone of the network, so that there is no dead corner of supervision. Through the management backstage, it can achieve the management of the intelligent supervision terminal such as on-line supervision, track replay, remote switching and locking and real-time status, etc. The device has a built-in 15000mAh battery, which meets the requirements for in-transit supervision of cargo transport in multiple scenarios.

Features

Large-Capacity Storage

Wireless Mutual Transmission

Dual SIM

Ultra-long Battery Life

Vibration Sensing Detection

Strong Adsorption

Parameters

Model

MVCM5110

SIM Card Type

Supports dual-mode positioning (GPS+BDS) for accurate positioning

Memory Card

32G

Positioning Method

GPS/BDS

Communication Mode

4G/Bluetooth/RFID/NFC

Unlocking Method

Support background/Bluetooth/RFID/NFC/APP

Battery Capacity

15000mAh

Battery Life

1min/sub data upload standby about 15 days; 1hour/time data upload standby about 30 days

IP Rating

IP67

Operating Temperature

High temperature ≤ 70℃, low temperature ≥ -30℃

Charging Method

DC 5V charging

Lock Body Size

193.5mm*107mm*39.5mm
