Introduction

Maxvision Palm Vein Based ldentity Authentication Terminal A107 adopts Al technology, combined with scientific applications such as vision, optics, acoustics, biology, etc., to obtain the corresponding palmar vein distribution map after irradiating the palm, Through dedicated comparison algorithms for biometric recognition, it achieves ultra-high securitv level personal identitv authentication. The equipment has the advantages of safety, reliability, non-contact, good anti-interference, and high accuracy. It can be integrated into intelligent devices such as access control, gate machines, self-service terminals. And it is widely used for personnel access control in customs, border defense, seaports, communities, buildings.

Features

Palm Vein ldentification

lmage Storage

Self-developed AI Algorithm

Entry/Exit Records

Interactive Guidance

Multi-Mode Management

Parameters

Model

MVNT-8680-A107-T0

Device Screen

7-inch high-definition LCD touch screen

Screen Resolution

1280*800 resolution; 800:1 contrast ratio

Device Capacity

1GB LPDDR3 8GB EMMC

Operating System

Linux

Processor

Quad-core Arm Corte XA7 32-bit core 2.0Tops

Palm Vein Recognition Accuracy

Rejection rate <0.4% when false positive rate <0.0001

External Communication

Default data transmission through LAN port or RS232interface, optional 4G, Bluetooth, WiFi and other wirelesstransmission modules; optional RS485 * 1, Wiegandin/out * 1, USB* 2; support for offline use

Operating Voltage

DC12VI2A

Operating Temperature

30-70°C

Working Humidity

10%RH~95%RH

Operation Environment

Indoor

Installation

Wall-mounted or desktop mounted
