Introduction

Maxvision lnteligent Face Recognition Terminal adopts integrated tempered glass panel protection design, equipped with 8-inch IPS HD display, which can be applied to all kinds of places requiring face recognition authentication. The product uses independently developed face recognition algorithm. The quality of face images captured by this device would not be impacted by different lighting circumstances (e.g., weak light, backlight, strong light). Functioning mask-wearing, glass-wearing, hat-wearing, face-covering, and liveness detection with the recognition rate of all these deep learning-powered feature matching algorithms have been up to 99%.

Features

Face-Covering Attribute Detection

99% face recognition rate

120dB Wide Dynamics

90°Wide-Angle Recognition

Strong Backlight Adaptation

Liveness Detection

Parameters

Screen Size

8 inch

Screen Resolution

1280*800 pixel

Screen Type

HD IPS Screen

CPU

4 Cores

RAM

1GB

Memory

Standard 8GB Memory

Camera

WDR Dual Camera System with 2MP

Recognizable Distance

0.2m ~ 3m

Maximum Authentication

10,000 Human Faces (Can be upgraded to 20,000 or 50,000)

Capacity

FAR (False Acceptance Rate)<0.01%, FRR (False Rejection Rate)

Accuracy

<1%, Comparison Time <100ms

Communication Port

LAN, RS232

Control Interface

Relay Output*1

Working Enwironment

Indoor/Outdoor

Protection Grade

IP55

Installation

Hanging

Size

235mm*130mm*20mm

Input Voltage

DC12V/2A

Working Temperature

-20-60°C
