Introduction

Maxvision Electric sliding door is a personnel control product used in multiple occasions, The main body of the Electric sliding door was made of 304 stainless steel + high permeability tempered glass; It was designed with DC brushless servo motor, super "core" , extremely quiet, long life; Telescopic door design.fast running speed, low site inspection space requirements. It can be flexibly integrated with other products, and widely used in communities, parks, enterprises, schools and other places entrance and exit.

Features

Precision Movement,Stable and Reliable

Brushless Motor.Efficient Opening and Closing

Intrusion Detection.Anti-intrusion and Anti-pinch

Telescopic Door Design Makes Flexible Inspection Space

Parameters

Work Voltage

DC24V

Opening/Closing Speed

≤1S (Adjustable)

Noise

≤50dB

Service Life

≥10 Millions Times

Communication Interface

RS232

Movement Type

Telescopic

Operating Environment

Indoor

Passage Width

900mm

Drive Motor

Servo Motor

Rated Torque

≤32N·m

Dimension

50mm(L)x330mm(W)x1000(H)
